The HD Video Conference Camera MG104-SG offers perfect functions, superior performance. The features include advanced ISP processing algorithms to provide vivid images with a strong sense of depth, high resolution, and fantastic color rendition. Working stably and reliably; easy and convenient to install and maintain.
1. Superb High-definition Image:
With high quality CMOS sensor. Resolution is up to 1920x1080 with frame rate up to 30fps.
2. Multiple Video Compression:
Support H.264, MJPEG, YUY2, NV12 video compression, to made video play smoothly.
3. Distortionless lens:
85° wide view angle non-distortion lens.
4. Stereo sound:
Built-in pick-up to present clear stereo sound effect, no need to connect external device.
5. USB2.0 interface:
Plug and play function is better for power supply and upgrading.
6. Multiple installation:
Easy to install on any device, say, LCD screen, laptop, table or tripod.
7. Wide Application: Personal video conferencing, live video conference, collaboration meeting etc.
Technical Specifications
|
Model Number |
MG104-SG |
|
Camera Parameters |
|
|
Sensor |
high quality HD CMOS sensor |
|
Effective Pixels |
16：9 ,2.07 megapixels |
|
Video Format |
1920x1080@30fps/25fps;1600x896@30fps/25fps;1280x720@30fps/25fps; 1024x576@30fps/25fps;960x540@30fps/25fps;800x600@30fps/25fps; 800x448@30fps/25fps;720x576@30fps/25fps;720x480@30fps/25fps;640x480@30fps/25fps;640x360@30fps/25fps;480x270@30fps/25fps;320x240@30fps/25fps; 352x288@30fps/25fps; 320x240@30fps/25fps;320x180@30fps/25fps |
|
View Angle |
92°（D）/85°（H）/ 52°（V） |
|
Focal Length |
3.24mm |
|
Minimum illumination |
0.5Lux(F1.8, AGC ON) |
|
Focus |
Manual |
|
Aperture |
Fixed |
|
Backlight Contrast |
On/OFF |
|
Exposure |
Exposure parameter could be adjusted; support auto exposure |
|
Video Adjustment |
Brightness, Color, Saturation, Contrast, White balance mode, Gain, Anti-flicker, Low brightness compensation etc |
|
SNR |
>50dB |
|
Input/Output Interface |
|
|
Video Interfaces |
USB2.0 (power supply, upgrading available) |
|
Video Compression Format |
MJPEG,YUY2, H.264, NV12 |
|
Audio Input Interface |
Built in omnidirectional high sensitive digital pickup |
|
Other Parameter |
|
|
Input Voltage |
5V |
|
Input Current |
500mA(Max.） |
|
Power consumption |
2.5W(Max.) |
|
Store Temperature |
-10℃～+60℃ |
|
Store Humidity |
20%～95% |
|
Working Temperature |
-10℃～+50℃ |
|
Working Humidity |
20%～80% |
|
Dimension（WXHXD） |
102mm*47mm*30mm |
|
Weight (appx.) |
0.15kg |
|
Application |
Indoor |
|
Accessory |
User Manual |
